Cutaneous renewal (resurfacing) with CO2 LASER has been recognized as a modern and efficient technigue for the treatment of facial wrinkles and photoaging. Surgery with LASER provides removal of epidermis and derma thin layers with absolute control of hemostasis, which allows for surgi cal steps to be accurately followed. Resurfacing is a new procedure that should integrate complex concepts related to dermatology, surgery, LASER Physics and healing processo.
When evaluating and treating patients with CO2 LASER, the surgeon should observe the skin nuances and its regeneration ability. Human skin is better viewed as a layered laminar structure vertically perforated by hair and other cutaneous adnexa. Derma may be divided into superficial or papillary and deep or reticular derma. Epidermis is composed by several specialized layers, the most important being the basal layer, that has the ability of regenerating epidermis through miotic division each six months or eight weeks(1).
In order to understand LASER cutaneous renewal (resurfacing) we must clarify certain parameters of facial wrinkle ablation and reduction with no residual scars.
The state-of-the-art equipment that work with CO2 LASER are the ultrapulsed ones, that emit enough energy to vaporize tissue with one single pulse and at a lower time interval than that of the thermal relaxation, avoiding heat diffusion and performing the selective photothermolysis of the target tissue. The CO2 LASER Ultrapulse 5000 C releases energy up to 350 millijoules at less than 1 meter per second, discharging up to 1000 pulses and promoting ablation, i.e., the safe and predictable removal of a given tissue volume(2).
Face is divided into cosmetic zones that vary considerably in thickness, appearance and sebaceous characteristics. Depth and effectiveness of cutaneous renewal (resurfacing) may vary with the change of the number of passing, and energy and density used.
The extremely thin eyelid skin deserves special considerations due to the risk of bad results such as ectropion or apparent scar. When observing the patients operated with Ultrapulse CO2 LASER with CPG, submitted to upper blepharoplasty, lower transconjunctival and cutaneous renewal (resurfacing) throughout the periorbital cosmetic unit, we noticed a great improvement in the skin quality with the erasure or considerable attenuation of the thin and rough wrinkles.
Immediate or delayed histological changes occurring at eyelid skin after CO2 LASER use were little studied and are not much conclusive(3, 5, 6).
The purpose of this work is to accurately evaluate the changes occurring at thin eyelid skin after cutaneous renewal with Ultrapulse CO2 LASER with CPG, and analyze me penetration depth, the use of proper energy, the accurate number of passing, me ephitelization and me effects at medium and long term.
MATERIAL AND METHODS
Twenty-six patients were selected for this study. None of them had been previously submitted to blepharoplasty or chemical exfoliation of skin. All patients were submitted to pre-operative treatment according to a protocol that included the use of 0.025% retinoic acid, 4% hydroquinone and photoprotector for three to five weeks before surgery.
The patients were submitted to upper transcutaneous blepharoplasty, lower transconjunctival blepharoplasty and cutaneous renewal (resurfacing) of me periorbital cosmetic unit,except for me upper pretarsal skin, with Ultrapulse CO2 LASER. Twenty-two patients (84.6%) were females and 4 patients (15.4%) were males. Nineteen patients (75%) were classified as type III and 7 patients (25%) were classified as type II according to Fitzpatrick's(7) classification for skin, hair and eye color.
Age of patients ranged from 43 to 72 years old, with 56-year average.
All patients presented varying degrees of skin photoaging with me presence of thin and rough wrinkles in variable amounts.
The equipment used to perform selective photothermolysis was series 5000 C Ultrapulse CO2 LASER with computer pattern generator (Coherent Medical Group, Palo Alto, California).
Upper blepharoplasty was performed after subcutaneous infiltration of 0.5% lidocaine with adrenaline at concentration of 1:400,000. Skin segments taken out from skin did not exceed 45 millimeters long and 7 millimeters wide.
Selective photothermolysis of periorbital aesthetic unit was performed after upper and lower transconjunctival blepharoplasty sparing upper pretarsal area. Ray release was ultrapulsed with 300-millijoule energy and 60 watt power in me first passing, and 200-millijoule energy and 40 watt power in the second passing. Pattern used was number 6 with 6 horizontal and vertical points with diameter 2.25 and density number 6.
Mechanical removal of reminding devitalized tissue with gauze soaked with 0.9% sodium chloride physiological solution was carried out after each LASER passing followed by drying of all areas.
Following, upper eyelid preseptal skin pieces were removed from saline, dried and divided into pieces of similar area. A passing of C02 LASER upon one piece, two passing upon the next piece and no passing upon me last piece were carried out according to me same selective phototherrnolysis of periorbital aesthetic unit parameters. These eyelid cutaneous pieces were preserved into 0.9% sodium chloride solution and 10% formaldehyde at 3:1 ratio and sent to histopathologic analysis.
After three months, six months and one year after selective phototermolysis, biopsies of the upper lateral preseptal skin from 26 patients were carried out following the same care and for the same purposes of those for me pieces previously examined.
Staining methods used for all pieces were as foliows:
HE: for architecture overall evaluation
Gomori: for architecture overall evaluation
PAS: for basal membrane evaluation
Resorcina-fuccina: for elastic fiber analysis
Alcian blue: for glucosamineglucan evaluation
Picrus sirius: for collagen fiber evaluation
Masson-Fontana: for melanin evaluation
RESULTS
The results of histopathologic analysis before and after selective photothermolysis and after cutaneous renewal process are described as follows.
1. Histopathologic analysis of thin eyelid skin before selective photothermolysis (Figs. 1, 5 and 7).
Fig. 1 - Microphotograph showing an advanced process of cutaneous photoaging. Epidermis presents itself even and atrophied with cell changes in its layers. Evident dermal changes with varied elastosis degrees. Collagen fibers present themselves thick with fragmented segments (HE).
Fig. 5 - Pre-operative histological section showing cutaneous aging aspects and typical epidermal and dermal changes (Gomori).
Fig. 7 - Post-operative histological analysis. Thin epidermis with cell polarity loss. Cell atypia and irregularities of the melanin deposit distribution were observed. Derma showing typical aging changes (HE).
Ali pieces showed an advanced photoaging processo Epidermis presents itself flat and atrophic. Keratinocytes present atypia and vary in form, size and pigmentation cytoplasmatic characteristics. Melanocytes along basal layer present themselves increased both in size and number. Masson - Fontana staining shows dense irregularly distributed melanin deposits, Cell adhesion is jeopardized, with a clear loss of cell polarity. Dermal changes are evident, with varied degrees of elastosis. Collagen fibers present themselves thickened with fragmented segments.
Glucoamineglucans are found to be highly increased, occupying the spaces where collagenolisis occurred. Dermal elastosis is clear both at superficial derma and at the deeper one.
2. Histopathologic analysis of thin eyelid skin.
Selective photothermolysis after the first passing of LASER, using 300-millijoule energy.
Epidermis and basal membrane ablation.
Presence of necrosis from superficial papillary dermis coagulation. Minimal thermal reaction of papillary derma with contraction of the most superficial collagen fibers.
Dermal adnexa preserved (Fig. 2).
Fig. 2 - Histological analysis after first passing of CO
2 LASER using 300-millijoule energy. Epidermis ablation and basal membrane with the presence of necrosis strip from papillary derma with contraction of more superficial collagen fibers. Dermal adnexa preserved (HE).
3. Histological analysis of eyelid skin. Selective photothermolysis after two passing of LASER using 200-millijoule energy at the first passing and 200-millijoule energy at the second passing. Deepening of necrosis from papillary derma coagulation. Integral basal membrane around cutaneous adnexa. Contraction of collagen fibers at a deeper plane of papillary derma. Elastic degeneration observed at papillary and medium derma is transformed into a coagulated mass.
4. Cutaneous regeneration after selective photothermolysis (Fig. 3). Epidermal regeneration with a reconstituted and completely uniform basal membrane was observed in the third post-operative month.
Fig. 3 - Histological analysis after second passing of C0
2 LASER using 200-millijoule energy. Deepening of necrasis from derma papillary coagulation was observed. Basal membrane is integral around preserved dermal adnexa. Contraction of collagen fibers at a deeper plane (HE).
Keratinocytes present themselves normal, atypia was eliminated and polarity presents traces of recovery. Melanocytes show more regular distribution. Structural change at derma is still more important: a strip of normal collagen is evident at the papillary derma.
Formation of collagen is observed at horizontal bands parallel to surface. Completely regenerate derma, with a more even distribution of melanocytes was encountered in the sixth month. Derma shows reconstruction and collagen fiber proliferation with redirection and compacting of papillary derma fibers. Collagen is more abundant and organized while glucosamineglucans have concurrently decreased. Elastosis of deeper derma is observed (Fig. 6). More defined histological patterns are observed one year after selective photothermolysis,. Epidermis completely regenerated with an aspect of young skin. Cell polarization is more structured, with an increased cell proliferating activity being observed. Epidermal cell layers are quite evident. Return of regularity of the melanin deposits at basal keratinocytes.
Fig. 6 - Histological evaluation after sixth month. Regenerated epidermis and great derrnal change. Collagen fiber proliferation with redirection and compacting of papillary derma fibers were observed.
A large band of newly formed collagen at superficial derma, with a great and evident decrease of glucosamineglucans at derma are observed. Elimination of elastosis at superficial and medium derma, with re-structure of the superficial dermal elastic system. (Figs. 4 and 8).
Fig. 4 - Histological evaluation after one year.Completely regenerated thin epiderrnis with young skin aspect.Great dermal changes with a large band of newly formed collagen at superficial derma were observed. Elastosis elimination from superficial and medium derma. Young skin aspect (HE).
Fig. 8 - Histological analysis after one year. Complete, regenerated and thick epidermis. The epidermal cell layers are quite evident, with cell polarization retaking. Regularization of melanin deposits on basal keratinocytes. Derma showing a large band of normal collagen (HE).
All these findings are compatible with the great aesthetic change observed in the cases operated.
DISCUSSION
Cutaneous regeneration (resurfacing) with CO2 LASER is an accurate and effective method for the treatment of cutaneous photoaging(8, 9). Shoenrick et al(5), Chernoff et al(1O) Weinstein(6) and Apfelberg(11) described the use of CO2 LASER upon the periorbital area. David et al(l2) described the use of CPG scanner.
Scanner allows for a precise control of overpassing, a parameter called density. Photothermolysis became absolutely accurate with the specification of three parameters: energy, density and number of passing.
When Ultrapulse CO2 LASER with CPG is used, the first passing produces epidermis ablation and some thermal reaction at superficial papillary derma. The superficial vaporization is equivalent to approximately 50 to 60m in depth(5, 10). An additional thermal necrosis of 50 to 70m is also observed. The second passing destroys little tissue as there is less water to absorb LASER energy, however, it produces a thermal injury of approximately 40 to 60m(3). Eyelid skin presents epidermis with depth ranging from 50 to 130m and derma with depth from 215 to 300m. Two passing of CO2 LASER remove epidermis and superficial derma with extreme precision, eliminating the thin periorbital wrinkles.
We concluded that an important dermal segment is preserved, keeping cutaneous adnexa integral or with the basal membrane preserved at the lower portion.
Thus, tissue ablation and subsequent thermal damage do not injure dermal adnexa that are vital for the skin ephitelization processo Burkhardt and Maw(l5) recently concluded that tissue injury induced by the use of Ultrapulse CO2 LASER with CPG in multiple passing is confined to reticular derma, sparing adnexal structures responsible for re-ephitelization.
The most important cell in healing process after photothermolysis is the specialized keratinocyte from pileous follicle sheath. A great number of these cells form the upper portion of pilosebaceous channel where it binds to epidermis. Keratinocytes and pilosebaceous complexes are spared during resurfacing and under special circumstances revert to an embryogenic state and are differentiated into epidermal cells that emerge through pilosebaceous channel and reephitelize the cutaneous surface(1). (Figs. 9a, 9b and 9c).
Fig. 9a - Pre-operative histological analysis. Epidermis and basal membrane (arrow) are observed (PAS).
Fig. 9b - Histological analysis after the second passing of CO
2 LASER. A vaporization of superficial cell occurs in the first passing that is equivalent to approximately 50 to 60m in depth. Also an additional thermal necrosis of 60 to 70m occurs. The second passing destroys little tissue, however it produces a thermal injury around 40 to 60m, as showed in figure. Photothermolysis spares dermal adnexa and preserved basal membrane is observed (arrow). Tissue ablation and thermal damage do not injury dermal adnexa vital for skin ephitelization process (PAS).
Fig. 9c - Histological analysis after the third month showing regenerated epidermis and basal membrane integrity (PAS).
We have observed that clinical re-ephitelization of aesthetic periorbital unit occurs between six and ten days for most patients.
Our histological findings confirm changes described by Stuzin(16) that show complete epidermal regeneration and the intense changes of facial derma.
Periorbital resurfacing using two passing of 300 millijoules and 200 millijoules provides an outstanding formation of neocollagen and the correction of dermal elastosis associated to a perfect and fast healing processo The transformation of the aesthetic pattern is remarkable (Figs. 10a and 10b).
Fig. 10a - Sixty-eight years old patient presenting advanced process of cutaneous aging and eyelid xanthelasma.
Fig. 10b - Post-operative at eighth month. Upper blepharoplasty, lower transconjunctival, resurfacing and canthexia were carried out. Cutaneous regeneration of the whole periorbital aesthetic unit.
We believe that the ideal model of periorbital resurfacing - with excellent aesthetic results, low rate of complications and proven histological changes being kept for the long term - is obtained with the employment of Ultrapulse CO2 LASER with CPG.
REFERENCES
1. MEHGREN AH. Pinku's guide to dermathology. Ed.4 East Norwalk, CT.: Appleton-Century- Crofts. 1986; p. 16.
2. FITZPATRICK RE, GOLDMAN MP, SATUR NM et al. Pulsed carbon dioxide laser resurfacing of photoaged facial skin. Arch. Dermatol. 1996; 132:395-402.
3. COTTON J, HOOD AF, GONIN R. et al. Histologia evoluation of preauricular and postauricular human skin after higt-energy short pulsed carbon dioxide laser. Arch. Dermatol. 1996; 132:425.
4. YANG CC, CHAIN CY. Animal study of skin resurfacing using the Ultrapulse carbon dioxide laser. Ann. Plast. Surg. 1995; 35:154.
5. SCHOENROCK LD, CHERNOFF WG, RUBACH BW Cutaneous Ultrapulse Laser Resurfacing of the lids. Int. J. Aesthetic Res. Surg. 1995; 3:31-36.
6. WEINSTEIN C. Ultrapulse carbon dioxide laser removal of periocular wrinkles in association with laser blepharoplasty. J. Clin. Laser Med. Surg. 1994; 12:205-209.
7. FITZPATRICK TB. The validity and practicality of sem retive skin types I through VI. Arch. Dermatol. 1988; 124:869-871.
8. FITZPATRICK RE, RUIZ-ESPARZA JN, GOLDMAN MP. The depth of necrosis resurg. The CO2 laser: A comparison of the superpulsed mode and conventional modes. J. Dermatol. Surg. Oncol. 1991; 17:340.
9. ALSTER TS, GARGS S. Treatment of facial rhytides with a higt-energy pulsed carbon dioxide laser Resurfacing. Int. J. Aesth. Rest. Surg. 1975; 3:57.
10. CHERNOFF WG, SCHOENROCK LD, CRAMER H, WAND J. Cutaneous laser Resurfacing. Int. J. Aesth. Rest. Surg. 1995; 3:57.
11. APFLBERG DB. The ultrapulse carbon dioxide laser with computer pattern generator automatic scanner for facial cosmetic surgery and resurfacing. Ann. Plast. Surg. 1996; 36:522-529.
12. DAVID LM, SARNE AJ, UNGER WP. Rapid laser scanning for facial resurfacing. Dermatol. Surg. 1995; 21:1031-1033.
13. KAUVAR ANB, GERONEMUS RS. Hitology of laser resurfacing. Dermatol. Clin. 1997; 15:459-467.
14. GONZALEZ-ULLOA M et al. Preliminary study of the total restoration of the facial skin. Plast. Reconstr. Surg. 1954; 13:151-16l.
15. BURKART BR, MAW R. Are more passes better? Safety versus efficacy with the pulsed CO2 Laser. Plast. Recontr. Surg. 1997; 100:1531-1534.
16. STUZIN JM, BAKER TM, na KLIGMAN M. Histology effects of the higt-energy pulsed skin. Plast. Recontr. Surg. 1997; 99:2036-2050.
