Circumferential congenital scar on the lower limb due to amniotic band syndrome addressed with Wplasty
Cicatriz congênita circunferencial em membro inferior devido à síndrome da banda amniótica abordada com dablioplastia

INTRODUCTION

Amniotic band syndrome (ABS) comprises a wide range of congenital changes attributed to the constriction of fetal parts in fibrous chorioamniotic rings. Its incidence is estimated between 1:1200 and 1:15000 live births¹.

To clarify the etiology of this syndrome, several theories have emerged. Initially, in 1930, Streeter presented the endogenous theory, in which defects in the germplasm with diffuse vascular rupture and chorioamniotic morphogenetic alterations result in the formation of fibrotic bands and abnormalities of fetal development. In 1968, Torpin² proposed the exogenous theory, in which the rupture of the amnion before the 12^th week, caused by exogenous factors, would provide direct contact between the fetus and the chorionic surface, with consequent oligohydramnios following extravasation of the amniotic fluid and easy protrusion through the rupture. Thus, favoring the formation of amniotic fibrous bands in the ruptured portion, which compromises the development of the structures involved distal to the band³, ⁴.

Both theories explain the presence of malformations of the limbs, abdominal wall, internal organs, and craniofacial⁵. Constrictions can result in extensive symptoms, from lymphedema, intrauterine amputations, syndactyly, congenital clubfoot, and death¹. There are no known factors that have statistically proven associations with ABS. Some conditions that are related, but are not statistically significant, include primiparous women, age under 25 years, collagenopathies, trauma resulting from attempted abortions, abnormal glycemic indices, and prematurity⁶, ⁷.

Patterson listed the diagnostic criteria based on the symptoms in order of increasing severity as a way of stratifying the symptoms as follows: 1) simple constriction rings with a normal end distal to the ring; 2) ring with distal atrophy and lymphedema; 3) ring with syndactyly on the affected extremities; 4) ring that causes amputation¹, ⁸.

OBJECTIVE

Because of the above, this work aims to report a case of a congenital circumferential scar on the lower limb due to amniotic band syndrome in a 2-year-old female patient, detailing the therapy used, in addition to carrying out a literature review. detailing the surgical approach to this syndrome, thus helping clinical management and the prognosis of future cases related to ABS.

METHOD

This is a documentary and retrospective study, carried out through an active search of the medical records of a patient diagnosed with ABS at the Walter Cantídio University Hospital (HUWC), in the city of Fortaleza, Ceará, Brazil. The hospital is a unit that provides highly complex health care, in addition to being a reference for the training of human resources and the development of research in the health area. Provides support for the tertiary care network in the state of Ceará, serving patients from the Unified Health System (SUS). Relevant information was collected by evaluating the patient’s medical records.

Regarding ethical aspects, the present project, as it is research with human beings, was submitted for evaluation by the HUWC Research Ethics Committee following Resolution 466/12 of the National Health Council (CNS). All established ethical precepts will be respected concerning ensuring the legitimacy of information, preserving anonymity, privacy, and confidentiality of information taken from the patient’s medical record.

CASE REPORT

A female patient, 2 years old, from a twin pregnancy with feto-fetal transfusion syndrome discovered in the 17^th week of pregnancy. After a week, an intrauterine fetoscopy was performed to correct the syndrome; however, the second fetus died on this occasion. Born by premature cesarean section (26 weeks of gestation), with fetal distress and weighing 635g (small for gestational age - SGA).

She was intubated shortly after birth due to the immaturity of her respiratory system, requiring three doses of surfactant - the first at 40 minutes of life. In this context, she remained hospitalized in the Intensive Care Unit (ICU) for 93 days, 57 days of which were on mechanical ventilation. During hospitalization, she developed necrotizing enterocolitis, stage IIIb, requiring exploratory laparotomy with the creation of an ileostomy.

Furthermore, during his hospital stay, he also presented: early and late neonatal infections, fungal infection, bacterial pneumonia, and grade I peri-intraventricular hemorrhage (IVPH), in addition to a convulsive episode that ended with the use of phenobarbital. She was discharged from the hospital 3 months and 28 days after her birth, clinically stable.

At 7 months of age, she was diagnosed with an amniotic band scar on her left lower limb, precisely in the ipsilateral calf region, which caused significant constriction of the limb, compromising its physiological growth and development (Figure 1). Therefore, she was recommended surgical correction and was referred to the plastic surgery service.

Figure 1 - Circumferential scar resulting from an amniotic band on the lower limb.

Figure 1 - Circumferential scar resulting from an amniotic band on the lower limb.

The scar retraction correction procedure was performed in the affected region, using Wplasty with the patient under general anesthesia, on August 8, 2022 (Figure 2). Anesthetic infiltration with epinephrine was performed, followed by infusion and detachment of the retracted area. Incisions continued to relax the fascia, as well as rigorous hemostatic inspection. The plans were closed.

Figure 2 - Intraoperative wound of the “W” Z-plasty approach.

Figure 2 - Intraoperative wound of the “W” Z-plasty approach.

In the immediate postoperative period (PO), the patient developed an intact surgical wound, without tension on the limb and with the region distal to the wound well perfused (Figure 3). She was discharged from the hospital on the 1st day of PO, without complaints, and was advised to return to the outpatient clinic after three days.

Figure 3 - Immediate postoperative wound, without tension and with good perfusion distal to the site addressed.

Figure 3 - Immediate postoperative wound, without tension and with good perfusion distal to the site addressed.

At the time of return, the surgical wound was without inflammatory signs, without dehiscence, and with well-coadapted edges that were not tensioned (Figure 4). The second evaluation, on the 18th postoperative day, found an ideal appearance of the wound, as well as preserved normal tension. The stitches were removed and continued on an outpatient basis (Figure 5).

Figure 4 - Wound on the 3^rd postoperative day, well covered and without dehiscence.

Figure 4 - Wound on the 3^rd postoperative day, well covered and without dehiscence.

Figure 5 - Wound on the 18^th postoperative day, with preserved tension and adequate appearance.

Figure 5 - Wound on the 18^th postoperative day, with preserved tension and adequate appearance.

DISCUSSION

As it is a rare congenital condition, most of the literature on amniotic band syndrome (ABS) still consists of case reports, with less diversity in the theoretical approach to this condition⁹, ¹⁰.

Regarding recognized therapies, the possibility of surgical treatment strongly depends on the topography and functionality of the affected organ. The presence of noticeable deformity with or without lymphedema indicates surgical intervention. The approach can be performed between 3 months and 2 years of age unless there is the possibility of significant neurovascular involvement or lymphedema. This does not contraindicate performing the release later, but the results concerning limb growth are enhanced when the intervention is early¹¹, ¹².

Lower limb constriction associated with clubfoot is the most prevalent deformity in Brazil, followed by upper limb involvement⁹, ¹¹. However, epidemiology differs concerning international articles, which define the upper limbs as the most affected area, with emphasis on the fingers⁷, ¹³.

Among the anatomofunctional deformities that may be included in the list of consequences of ABS, Drury & Rayan¹³ listed: partial limb constriction, complete constriction band, intrauterine amputation, fenestrated acrosyndactyly, partial syndactyly, bone growth at the site of intrauterine amputation, deficient interdigital space, lymphedema, remaining digits, ectopic implantation of amputated fingers in another part of the body, proximal interphalangeal joint contracture, nerve compression, complete nerve rupture, among others.

From this perspective, indications range from bridle resection, with deep dissection and release of the neurovascular bundle, flap reconstruction using Z-plasty, Wplasty, and even, in the most serious cases, amputation of affected limbs. When the upper or lower limb is affected in isolation, the release of the retracted structures with subsequent Z-plasty, single or multiple, has a high potential for a good prognosis, with single procedures having fewer reports of complications.

Furthermore, the bibliography points out that the Wplasty approach, despite not having a significant number in practice, is seen as a safe technique with satisfactory postoperative results. In cases of lower limbs associated with foot involvement, surgical treatment in two sequential stages is recommended⁹.

In this case, the patient benefited from Wplasty therapy in just one surgical procedure, since the constriction was isolated to the left calf, and, despite there being growth delay, there was no tortuosity or deformity in the feet. According to the literature analysis, the one-stage surgical approach was not responsible for an increase in ischemic complications or the development of venous congestion¹².

However, the discussion regarding the circumferential constrictive band approach in one or more surgical stages remains fruitful. The issue discussed involves the personalization of treatment, necessary given the large number of possibilities for deformities resulting from the amniotic band. The importance of surgical planning is highlighted to obtain the best possible result within the child’s aesthetic and functional aspects⁷.

It must be analyzed which structures are affected, whether there is lymphedema, and the impact on the growth of the limb, among other factors. The approach in two or more surgical stages may be preferable in cases of association of multiple deformities (which would make it difficult to approach on just one occasion), blood or lymphatic circulation disorders in the distal segment, need to accommodate growth, and in patients who tend to worse healing (as more overt approaches can carry greater risks in this regard)¹¹, ¹², ¹⁴.

In any of these cases, mobilization of a fatty tissue flap may improve the aesthetics of the repair in the area of the constriction. After excision of the skin around the band, there may be an hourglass-shaped deformity of the affected limb, so that, even after resolution of the constriction, the patient remains with aesthetic impairment. One way to minimize this issue is to excise excess adipose tissue from surrounding areas¹¹.

It was decided to make an incision and detachment of the retraction area, followed by relaxing the local fascia through another incision, ending with closure in layers. Postoperatively, the patient had no complaints or bleeding. At ectoscopy, the wound was well closed, without tension or areas of dehiscence, and with adequate perfusion. She was discharged from the hospital and scheduled to return for outpatient follow-up.

CONCLUSION

As it is a disruptive malformation, amniotic band syndrome compromises the life of the fetus and alters its development, which can range from the amputation of one or more limbs to fetal death. Therefore, early diagnosis is extremely important so that the best approach can be chosen, which can be helped by applying the Patterson classification⁸, and the main point must be the preservation of the functionality of the affected limbs, aiming to improve the patient’s prognosis.

It should be noted that establishing a good doctor-patient relationship with parents is extremely important to reassure them both about the pregnancy and the child’s development. Furthermore, there must be a multidisciplinary treatment, intending to obtain better long-term results, whether functional or aesthetic.
